DOUTHITT VACUUM BLANKETS
For Every Printing Frame
ALL MAKES ALL MODELS SIZES 16 X 20 TO 86 X 270
DOUTHITT HEAVY DUTY SMOOTH UNIVERSAL BLANKET
A perfect blanket for all your platemaking and contact needs. The Blanket material consists of pure rubber sandwiched between layers of a grained canvas duck. This surface will not mark your glass or indent your plates or film. Available in any length with a maximum width of 80 inches (If length exceeds 180 Prices on request.)
PRICE Where the narrowest O.D. (D dimension on print) does not exceed 52 inches, the price is 28¢ per square inch.
Where it does exceed 52 inches, the price is 33¢ per square inch. No Set-Up Charge, No Crating Charge.
ANTI-STATIC PROPERTIES WOVEN INTO DOUTHITTS SMOOTH UNIVERSAL BLANKET MATERIAL
ALLOW FOR BETTER REGISTRATION.
SPECIAL FEATURE: Any section of S beading is easily replaceable on the Douthitt Universal Blankets. So, if you damage the beading, just order enough beading to replace the damaged section.
DOUTHITT DEEP DRAW BLACK GUM
For Direct Method Silk Screen Printing Frames (Textured Surface reduces drawdown time.)
Under vacuum this blanket swiftly molds itself to the shape of the silk screen frame and holds your positive in perfect contact. Available in any size.
PRICE Where the narrowest O.D. (D dimension on print) does not exceed 58 inches, the price is 22¢ per square inch. Where it does exceed 58 inches, the price is 21¢ per square inch. No Set-Up Charge, No Crating charge.
NOTE: When checking your blanket dimensions, remember A + X + Y = C and B + W + Z = D.
|VACUUM BLANKETS DO NOT COME WITH VALVES
3/8 Blanket Valve $25.45 ea.
5/8 Blanket Valve $29.95 ea.
